Shift Unit/Alignment Plate Drive - Develop ineo+ 6500 Service Manual

Theory of Operation Ver2.0 Sep.2006
6.2.4

Shift unit/alignment plate drive

LS drawing as seen from above. On the right side is the main body.
[5]
[1] Guide rail
[2] Alignment plate
[3] Alignment motor (M7)
[4]
[6]
[3]
[4] Shift unit
[5] Shift unit motor (M5)
[6] Guide rail
6. CONVEYANCE SECTION
[1]
[2]
ls502to2013c
19
