Theory of Operation Ver1.0 Sep.2006
CONFIGURATION/OPERATION
4. PAPER FEED SECTION
4.1
Configuration
Pick-up roller
Paper empty sensor
/1 (PS3), /2 (PS11)
Paper feed assist fans
Paper size sensors /Rt1 (PS5), /Lt1
(PS6), /Rt2 (PS13), and /Lt2 (PS14)
(Sub scan direction)
Paper lift plate
Paper size VR/1 (VR1) and VR/2 (VR3) (Main scan direction)
Paper up/down
assist mechanism
4. PAPER FEED SECTION
Paper feed
roller
Separation
roller
Remaining paper VR/1
(VR2) and VR/2 (VR4)
a03xt2c001ca
