Theory of Operation Ver1.0 Sep.2006
8. FOLDING/SADDLE STITCHING/TRI-FOLDING SECTION
8.1
Composition
Folding full sensor
(PS29)
Tri-folding stopper
Folding roller
Tri-folding roller
Folding paper exit sensor
(PS25)
Tri-folding gate
Folding full LED
(PS29)
Folding pass-through
sensor (PS26)
8. FOLDING/SADDLE STITCHING/TRI-FOLDING SECTION
Tri-folding gate solenoid (SD6)
Folding knife home sensor (PS22)
Folding knifeg
Folding knife motor
(M19)
Saddle stitching
stopper
Folding transfer motor
(M20)
a04dt2c008ca
51
