7. SCANNER SECTION
(3) When AE/ACS is set (DF mode)
[1] [2]
[4]
[5]
[14]
[1] Home position
[2] PS1
[3] Platen APS position
[4] White correction (First time)
[5] White correction (Second time)
[6] AE/ACS scan for the first page (409 mm/s)
[7] Exposure scan for the first page (270 mm/s)
[8] Timing of the original replacement
28
[3]
[6]
[9]
[12]
Theory of Operation Ver1.0 Sep.2006
[9] AE/ACS scan for the second page
(409 mm/s)
[10] Exposure scan for the second page
(270 mm/s)
[11] Timing of the original replacement
[12] AE/ACS scan for the last page (409 mm/s)
[13] Exposure scan for the last page (270 mm/s)
[14] Home position search
[7]
[8]
[10]
[11]
[13]
a03ut2c022ca
