1. PRODUCT SPECIFICATIONS
1.2 HT-503
A. Type
Type
B. Maintenance
Machine service life
C. Machine data
Power source
Maximum power consump-
tion
Dimensions
Weight
D. Operating environment
Temperature
Humidity
Note
• The information herein may be subject to change for improvement without notice.
2
Fan heater type dehumidifier device
Same as the main body.
24/5VDC, 200 to 240VAC (supplied both from the main body)
DC: 4W or less, AC: 290W or less
Dehumidifier fan heater unit: 293 (W) x 82 (D) x 197 (H) mm
Power unit: 121 (W) x 80 (D) x 160 (H) mm
Dehumidifier fan heater unit: Approx. 1.5 kg
Power supply unit: Approx. 0.9 kg
10 to 30°C
10 to 80%RH (with no condensation)
