Gate Drive - Develop ineo+ 6500 Service Manual

Theory of Operation Ver2.0 Sep.2006
4.2.2

Gate drive

[18]
[17]
[16]
[15]
[14]
[13]
[12]
[11]
[1] Entrance gate
[2] Entrance gate solenoid (SD1)
[3] Vertical conveyance roller /1
[4] Roller solenoid /1 (SD5)
[5] Roller solenoid /2 (SD6)
[6] Vertical conveyance roller /2
[7] Vertical conveyance roller /3
[8] Roller solenoid /3 (SD7)
[9] Roller solenoid /4 (SD8)
4. CONVEYANCE SECTION
[10] Vertical conveyance roller /4
[11] L size gate solenoid (SD4)
[12] L size gate
[13] S size gate solenoid (SD3)
[14] S size gate
[15] Sub tray gate solenoid (SD9)
[16] Sub tray gate
[17] Sub tray paper exit roller
[18] Paper exit solenoid (SD12)
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
fd501to2003c
17
