4. TRANSFER SECTION
4.3.4

Bypass gate control

The bypass gate is located in the paper path to the stacker section. The bypass gate is the gate to transfer the
subsequent paper during the stapling operation for eliminating the time loss and increasing the productivity.
A. Bypass gate operation
The bypass gate solenoid (SD5) [2] drives the bypass gate [1].
For the small size paper (A4, B5, and 8
to transfer the paper to the bypass route [3]. The 2nd page of the 2nd and following copies is transferred to the
regular route [4] and overlapped under the 1st page, and then the transferred to the stacker section.
[1]
[2]
[1] Bypass gate
[2] Bypass gate solenoid (SD5)
16
/ x 11), it operates only for the 1st page of the 2nd and following copies
1
2
[3]
[4]
[3]
[4]
Theory of Operation Ver1.0 Sep.2006
[3]
Bypass route
Regular route
15jkt2c006na
