Folding Main Scan Alignment Drive - Develop ineo+ 6500 Service Manual

Theory of Operation Ver2.0 Sep.2006
6.2.4

Folding main scan alignment drive

[6]
[5]
[1] Folding main scan alignment home sensor /Rr (PS19)
[2] Alignment stoppers /Rr
[3] Right side view
[4] Alignment claws /Fr
[8]
[7]
[4] [3]
[5] Folding main scan alignment motor /Fr (M7)
[6] Folding main scan alignment home sensor /Fr1 (PS18)
[7] Folding main scan alignment home sensor /Fr2 (PS49)
[8] Folding main scan alignment motor /Rr (M14)
6. FOLDING SECTION
[1]
[2]
