11. INTERMIDIATE TRANSFER SECTION
11. INTERMIDIATE TRANSFER SECTION
11.1 Configuration
Color registration sensor shutter /Fr
Color registration sensor shutter /Rr
PGC sensor shutter
Second transfer roller /Lw
Separation claw unit
48
Toner guide roller
Toner collection screw
Image correction unit
Second transfer roller /Up
Theory of Operation Ver1.0 Sep.2006
Belt cleaning blade
First transfer roller /Y
First transfer roller /M
First transfer roller /C
First transfer roller /K
Transfer belt
a03ut2c032ca
