Bundle Processing Section; Composition - Develop ineo+ 6500 Service Manual

Theory of Operation Ver2.0 Sep.2006

8. BUNDLE PROCESSING SECTION

8.1

Composition

Trimmer scraps
removal fan (FM1)
Bundle regis-
tration plate
Shutter
Trimmer scraps
press plate
Bundle press
Up down wire
stage
Registration
claws
Trimmer scraps full
sensor (PS41)
8. BUNDLE PROCESSING SECTION
Bundle press
plate
Bundle exit con-
Scraps box
veyance belt
Exit claws
Bundle tray
paper full sen-
sor (PS61)
Bundle exit tray
15ant2c050nb
