8. BUNDLE PROCESSING SECTION
8.2.4

Bundle press drive

[8]
[1] Bundle press plate /Up
[2] Release wire /Rt
[3] Wire winding shaft
[4] Bundle press motor (M23)
[5] Release wire /Lt
86
1
[7]
[5]
[6]
Theory of Operation Ver2.0 Sep.2006
[9]
[4]
[3]
[6] Front side direction
[7] Bundle press lower limit sensor (PS47)
[8] Bundle press home sensor (PS37)
[9] Spring
[1]
[2]
15ant2c054nb
