Theory of Operation Ver1.0 Sep.2006
13. TONER SUPPLY SECTION
13.1 Configuration
Toner supply door open/
close sensor (PS54)
Interlock switch /2 (MS2)
Piezoelectric sensor /C (PZS/C) Piezoelectric sensor /K
Piezoelectric sensor /Y (PZS/Y)
Toner supply motor /K (M52)
(PZS/K)
13. TONER SUPPLY SECTION
Piezoelectric sensor /M (PZS/M)
Toner bottle clutch /Y (MC14)
Toner supply motor /Y (M49)
Toner bottle clutch /M (MC15)
Toner supply motor /M (M50)
Toner bottle motor (M53)
Toner bottle clutch /C (MC16)
Toner supply motor /C (M51)
Toner bottle clutch /K (MC17)
a03ut2c041ca
59
