Drive - Develop ineo+ 6500 Service Manual

4. TRANSFER SECTION
4.2

Drive

[14]
[13]
[12]
[1] FNS transfer motor (M1)
[2] PI transfer roller
[3] Entrance roller
[4] Transfer roller /A
[5] Transfer roller /B
[6] Bypass gate
[7] Intermediate transfer roller
[8] Bypass gate solenoid (SD5)
[9] Paper exit belt
[10] Paper exit arm
[11] Gate
12
[15] [16]
[11]
[10]
[9]
Theory of Operation Ver1.0 Sep.2006
[17] [18] [19]
[8] [7]
[12] Shift roller
[13] Main tray exit roller
[14] Paper exit opening solenoid (SD4)
[15] Paper exit roller motor (M7)
[16] Sub tray paper exit motor (M21)
[17] Sub tray paper exit roller
[18] Paper exit motor (M8)
[19] Shift roller motor (M2)
[20] Sub tray transfer roller
[21] Gate motor (M12)
[20] [21] [1]
[2]
[3]
[4]
[5]
[6]
a04dt2c001ca
