3. PAPER PATH

3. PAPER PATH
3.1

Non-sort/sort/group mode

[5]
[4]
[1] Paper path from PI (PI-502 installed)
[2] Paper path from the main body
[3] Gate
6
[6]
[4] Main tray
[5] Paper exit unit
[6] Shift unit (sort/group mode only)
Theory of Operation Ver1.0 Sep.2006
[1]
[2]
[3]
a04dt1c002ca
