9. PHOTOCONDUCTOR SECTION
Drum motor /Y (M14)
Developing motor /Y (M20)
Toner supply motor /Y (M49)
Erase lamp /Y (EL/Y)
Charging corona /Y (HV/1)
Laser drive board /Y (LASDB/Y)
Developing bias /Y (DC) (HV/1)
Developing bias /Y (AC) (HV/1)
1st transfer /Y (HV/2)
Drum motor /M (M15)
Developing motor /M (M21)
Toner supply motor /M (M50)
Erase lamp /M (EL/M)
Charging corona /M (HV/1)
Laser drive board /M (LASDB/M)
Developing bias /M (DC) (HV/1)
Developing bias /M (AC) (HV/1)
1st transfer /M (HV/2)
Drum motor /C (M16)
Developing motor /C (M22)
Toner supply motor /C (M51)
Erase lamp /C (EL/C)
Charging corona /C (HV/1)
Laser drive board /C (LASDB/C)
Developing bias /C (DC) (HV/1)
Developing bias /C (AC) (HV/1)
1st transfer /C (HV/2)
Drum motor /K (M17)
Developing motor /K (M23)
Toner supply motor /K (M52)
Erase lamp /K (EL/K)
Charging corona /K (HV/1)
Laser drive board /K (LASDB/K)
Developing bias /K (DC) (HV/1)
Developing bias /K (AC) (HV/1)
1st transfer /K (HV/2)
Transfer belt motor (M18)
1st transfer pressure/release motor (M19)
2nd transfer pressure/release motor (M34)
2nd transfer CONT
Bias (HV/2)
2nd transfer (HV/2)
Separation (HV/2)
[1] M17 ON
[2] M14 ON
[3] M15 ON
[4] M16 ON
[5] M20 ON
[6] Start of writing (First toner image)
[7] V_TOP signal generation
[8] Finish of writing (First toner image)
44
[1][2] [3] [4] [5] [6]
[7]
Theory of Operation Ver1.0 Sep.2006
[8] [11] [12]
[9] [10] [13]
[9] Separation ON
[10] Start of second transfer
[11] Finish of writing (The last toner image)
[12] Finish of first transfer /Y
[13] Developing bias /K (AC) OFF (End of writing)
[14] Start of transfer belt release
[15] Charging corona /Y OFF
[16] Start of second transfer cleaning
[15]
[14] [16]
a03ut2c030ca
