7.23 Status Registers

Many status bit are available throughout the IO and HDMI Maps. These status bits are listed in
Table 32.
Bit Name
AVI_INFO_RAW
AUDIO_INFO_RAW
SPD_INFO_RAW
VS_INFO_RAW
MS_INFO_RAW
ACP_PCKT_RAW
ISRC1_PCKT_RAW
ISRC2_PCKT_RAW
Bit Name
GAMUT_MDATA_RAW
AUDIO_C_PCKT_RAW
GEN_CTL_PCKT_RAW
AUDIO_MODE_CHNG_RAW
Rev. F August 2010

Table 32: HDMI Flags in IO Map Register 0x60

Bit Position
1 (LSB)
2
3
4
5
6
7
8 (MSB)

Table 33: HDMI Flags in IO Map Register 0x65

Bit Position
1 (MSB)
2
3
4
184
Description
Returns 1 if an AVI InfoFrame was
received within last seven VSync.
Additional description available here.
Returns 1 if an AVI InfoFrame was
received within last three VSync.
Additional description available here.
Returns 1 if a Source Product
Descriptor InfoFrame has been
received. Additional description
available here.
Returns 1 if a Vendor Specific
InfoFrame has been received. Reset
to 0 following a packet detection flag
reset condition.
Returns 1 if a MPEG InfoFrame was
received within last three VSync.
Additional description available
Returns 1 if an ACP packet was
received within last 600 ms.
Additional description available
Returns 1 if an ISRC1 packet was
received. Additional description
available here.
Returns 1 if an ISRC2 packet was
received. Additional description
available here.
Description
Returns 1 if a Gamut Metadata
packet was received. Additional
description available here.
Returns 1 if an audio clock
regeneration packet has been
received. Reset to 0 following a
packet detection flag reset
Returns 1 if general control packet
has been received. Reset to 0
following a packet detection flag
reset condition.
Returns 1 if last audio packet type
received has changed from audio
sample, DSD or HBR to another type
ADV7604
here.
here.
condition.
