B_GAIN[9:0] Manual Gain Value for Channel B , CP Map, Address 0x74, [3:0]; Address 0x75,
[7:0]
Note : To change the B_GAIN[9:0] value, registers 0x74 and 0x75 must be written to in this order
2
with no other I C access in between.
Function
B_GAIN[9:0]
xx xxxx xxxx
0x100
C_GAIN[9:0] Manual Gain Value for Channel C , CP Map, Address 0x75, [1:0]; Address 0x76,
[7:0]
Note : To change the C_GAIN[9:0] value, registers 0x75 and 0x76 must be written to in this order
2
with no other I C access in between.
Function
C_GAIN[9:0]
xx xxxx xxxx
0x100
