Analog Devices Advantiv ADV7604 Hardware Manual page 397

Pin Mnemonic
B11 TVDD
C11 TVDD
D11 CVDD
G11 PVDD
H11 AGND
J11 AGND
K11 AGND
L11 AGND
M11 AGND
R11 FB_OUT
T11 RESETB
U11 P31
V11 P30
A12 RXB_2-
B12 RXB_2+
C12 TVDD
D12 DDCB_SDA
G12 PVDD
H12 AGND
J12 AGND
K12 AVDD
L12 AVDD
M12 AVDD
R12 SHARED_EDID
T12 AVLINK
U12 P33
V12 P32
A13 RXB_1-
B13 RXD_1+
C13 DGND
D13 DDCB_SCL
R13 HS_IN1
T13 VS_IN1
U13 P35
V13 P34
A14 RXB_0-
B14 RXB_0+
C14 DGND
Rev. F August 2010
Function
This pin is always connected to the Terminator
supply voltage (3.3 V).
This pin is always connected to the Terminator
supply voltage (3.3 V).
This pin is always connected to the Comparator
supply voltage (1.8 V).
This pin is always connected to the PLL supply
voltage (1.8 V).
Connect this pin to ground
Connect this pin to ground
Connect this pin to ground
Connect this pin to ground
Connect this pin to ground
Float this pin.
The level of this pin should be controlled by an
external processor.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
This pin is always connected to the Terminator
supply voltage (3.3 V).
Float this pin.
This pin is always connected to the PLL supply
voltage (1.8 V).
Connect this pin to ground
Connect this pin to ground
This pin is always connected to the Analog
supply voltage (1.8 V).
This pin is always connected to the Analog
supply voltage (1.8 V).
This pin is always connected to the Analog
supply voltage (1.8 V).
Float this pin.
Connect this pin to ground
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Connect this pin to ground
Connect this pin to ground via a 10k ohm resistor.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Connect this pin to ground
397
ADV7604
