Figure 46: Dsd Timing Diagram - Analog Devices Advantiv ADV7604 Hardware Manual

Notes:
• DSD0A and DSD0B output must be used when in stereo mode only. DSD0A and DSD0B
always carry the main 2-channel audio data.
• DSD1A, DSD1B, DSD2A, and DSD2B are the surround channels.
• With
OVR_AUTO_MUX_DSD_OUT
outputting a DSD stream when it detects DSD packets.
where:
xx is the channel, for example, 0A, 0B
2
The I S and DSD interfaces share the same pins. By default, the ADV7604 automatically enables the
DSD interface if it receives DSD packets. The ADV7604 also automatically enables the I
if it receives audio sample packets or if it does not receive any audio packets. However, it is possible
to override the audio interface that is used via the
MUX_DSD_OUT controls.
OVR_AUTO_MUX_DSD_OUT , HDMI Map, Address 0x02, [0]
Function
OVR_AUTO_MU
X_DSD_OUT
0
1
MUX_DSD_OUT , HDMI Map, Address 0x02, [1]
Function
MUX_DSD_OUT
0
1
Rev. F August 2010

Figure 46: DSD Timing Diagram

Description
Automatically enables DSD or I
packet received. DSD interface enabled if part receives DSD audio
2
sample packet. I S interface is enabled when part receives audio sample
packets or when no packet is received.
Overrides DSD versus I
MUX_DSD_OUT is set to 1. I
MUX_DSD_OUT is set to 0.
Description
2
Enables I S interface. OVR_AUTO_MUX_DSD_OUT must be set to 1
for MUX_DSD_OUT to be effective.
Enables DSD interface. OVR_AUTO_MUX_DSD_OUT must be set to
1 for MUX_DSD_OUT to be effective.
is set to 0, the ADV7604 will automatically switch to
OVR_AUTO_MUX_DSD_OUT
2
S interface according to the type of
2
S interface selection. DSD interface enabled if
2
S interface is enabled if
142
ADV7604
2
S interface
and
