Table 31: Registers Location For Sha-1 Hash Value V - Analog Devices Advantiv ADV7604 Hardware Manual

KSV Register Name
Number
20 KSV20[39:0]
21 KSV21[39:0]
22 KSV22[39:0]
23 KSV23[39:0]
1
All KSVs are located in the Repeater Map
Register
Name
SHA_A[31:0]
SHA_B[31:0]
SHA_C[31:0]
SHA_D[31:0]
SHA_E[31:0]
1
All registers specified in table are located in the Repeater Map
2
Refer to HDCP Protection System Standards
Rev. F August 2010

Table 31: Registers Location for SHA-1 Hash Value V'

1
Address Location
0x20[7:0]: SHA_A[7:0]
0x21[7:0]: SHA_A[15:8]
0x22[7:0]: SHA_A[23:16]
0x23[7:0]: SHA_A[31:24]
0x24[7:0]: SHA_B[7:0]
0x25[7:0]: SHA_B[15:8]
0x26[7:0]: SHA_B[23:16]
0x27[7:0]: SHA_B[31:24]
0x28[7:0]: SHA_C[7:0]
0x29[7:0]: SHA_C[15:8]
0x2A[7:0]: SHA_C[23:16]
0x2B[7:0]: SHA_C[31:24]
0x2C[7:0]: SHA_D[7:0]
0x2D[7:0]: SHA_D[15:8]
0x2E[7:0]: SHA_D[23:16]
0x2F[7:0]: SHA_D[31:24]
0x30[7:0]: SHA_E[7:0]
0x31[7:0]: SHA_E[15:8]
0x32[7:0]: SHA_E[23:16]
0x33[7:0]: SHA_E[31:24]
Register Addresses
0xE3[7:0]: KSV19[39:32]
0xE4[7:0]: KSV20[7:0]
0xE5[7:0]: KSV20[15:8]
0xE6[7:0]: KSV20[23:16]
0xE7[7:0]: KSV20[31:24]
0xE8[7:0]: KSV20[39:32]
0xE9[7:0]: KSV21[7:0]
0xEA[7:0]: KSV21[15:8]
0xEB[7:0]: KSV21[23:16]
0xEC[7:0]: KSV21[31:24]
0xED[7:0]: KSV21[39:32]
0xEE[7:0]: KSV22[7:0]
0xEF[7:0]: KSV22[15:8]
0xF0[7:0]: KSV22[23:16]
0xF1[7:0]: KSV22[31:24]
0xF2[7:0]: KSV22[39:32]
0xF3[7:0]: KSV23[7:0]
0xF4[7:0]: KSV23[15:8]
0xF5[7:0]: KSV23[23:16]
0xF6[7:0]: KSV23[31:24]
0xF7[7:0]: KSV23[39:32]
Function
H0 part of SHA-1 hash value V'. Register
also called (V'.H1)
H1 part of SHA-1 hash value V'. Register
also called (V'.H1)
H2 part of SHA-1 hash value V'. Register
also called (V'.H2)
H3 part of SHA-1 hash value V'. Register
also called (V'.H3)
H4 part of SHA-1 hash value V'. Register
also called (V'.H4)
180
ADV7604
1
2
2
2
2
2
