ADV7604
The recommended resistor values for voltages related to the D-terminal connector are shown in
Figure
15, the values for SCART are shown in
Figure
16.

Figure 15: D-Terminal Resistor Dividers

Figure 16: SCART Connector Resistor Dividers
