7.19.3 Customizing Packet/InfoFrame Storage Registers

The packet type value of each set of packet and InfoFrame registers in the InfoFrame Map is
programmable. This allows the user to configure the ADV7604 to store the payload data of any
packet and InfoFrames sent by the transmitter connected on the selected HDMI port.
AVI_PACKET_ID , InfoFrame Map, Address 0xE0, [7:0]
Function
AVI_PACKET_ID
0x82
0xxx xxxx
1xxx xxxx
AUD_PACKET_ID , InfoFrame Map, Address 0xE3, [7:0]
Function
AUD_PACKET_ID
0x84
0xxx xxxx
1xxx xxxx
SPD_PACKET_ID , InfoFrame Map, Address 0xE6, [7:0]
Function
SPD_PACKET_ID
0x83
0xxx xxxx
1xxx xxxx
MS_PACKET_ID , InfoFrame Map, Address 0xE8, [7:0]
Function
MS_PACKET_ID
0x85
0xxx xxxx
1xxx xxxx
Rev. F August 2010
Description
Default value
Packet type value of packet stored in InfoFrame Map, Address
0x00 to 0x1B
Packet type value of InfoFrame stored in InfoFrame Map,
Address 0x00 to 0x1B
Description
Default value
Packet type value of packet stored in InfoFrame Map, Address
0x1C to 0x29
Packet type value of InfoFrame stored in InfoFrame Map,
Address 0x1C to 0x29
Description
Default value
Packet type value of packet stored in InfoFrame Map, Address
0x2A to 0x45
Packet type value of InfoFrame stored in InfoFrame Map,
Address 0x2A to 0x45
Description
Default value
Packet type value of packet stored in InfoFrame Map, Address
0x46 to 0x53
Packet type value of InfoFrame stored in InfoFrame Map,
Address 0x46 to 0x53
