13.1 Main Controls

This section describes the main controls for the AV.link.
AVLINK_POWER_UP, AV.Link Section Enable , AVLINK Map, Address 0x27, [0]
Function
AVLINK_POWER
_UP
0
1
AVL_SOFT_RESET, AV.link Reset , AVLINK Map, Address 0x29, [0]
Function
AVL_SOFT_RESE
T
0
1
Note that the AVLINK_POWER_UP bit can be set in order to put the ADV7604 in power-down
mode 1 (refer to Section 3.2.1.2).

13.2 AV.link Transmit Module

This module incorporates the functions of the AV.link in the capacity of initiator. The host utilizes
this module to transmit a message to other AV.link devices by setting the mode of the frame, frame
header and data registers (refer to
outgoing message length register. The host then starts the transmission by setting the transmit enable,
AVL_TX_ENABLE, to 1. The AV.link controller starts the transmission process. When the message
transmission is completed, or if an error occurs, the AV.link transmitter module set a relevant status.
Register Name
AVL_TX_FRAME_HEADER[7:0]
AVL_TX_FRAME_DATA0[7:0]
AVL_TX_FRAME_DATA1[7:0]
AVL_TX_FRAME_DATA2[7:0]
AVL_TX_FRAME_DATA3[7:0]
AVL_TX_FRAME_DATA4[7:0]
AVL_TX_FRAME_DATA5[7:0]
AVL_TX_FRAME_DATA6[7:0]
AVL_TX_FRAME_DATA7[7:0]
AVL_TX_FRAME_DATA8[7:0]
AVL_TX_TX_FRAME_DATA9[7:0]
AVL_TX_TX_FRAME_DATA10[7:0]
AVL_TX_TX_FRAME_DATA11[7:0]
Rev. F August 2010
Description
Disables the AV.link section
Enables the AV.link section
Description
Do not reset the AV.link section.
Reset the AV.link section. This bit is self clearing
Table 80) and other transmit related control registers such as the

Table 82: AV.link Outgoing Message Buffer Registers

AVLINK Description
Map
Address
0x01 Header of next outgoing message
0x02 Byte 0 of next outgoing message
0x03 Byte 1 of next outgoing message
0x04 Byte 2 of next outgoing message
0x05 Byte 3 of next outgoing message
0x06 Byte 4 of next outgoing message
0x07 Byte 5 of next outgoing message
0x08 Byte 6 of next outgoing message
0x09 Byte 7 of next outgoing message
0x0A Byte 8 of next outgoing message
0x0B Byte 9 of next outgoing message
0x0C Byte 10 of next outgoing message
0x0D Byte 11 of next outgoing message
