Analog Devices Advantiv ADV7604 Hardware Manual page 394

Pin Mnemonic
M2 DGND
N2 DVDDIO
P2 P11
R2 P13
T2 P15
U2 P17
V2 P18
A3 RXD_1-
B3 RXD_1+
C3 TVDD
D3 RXA_5V
F3 EP_MISO
G3 EP_CS
H3 RAW_VSYNC
J3 MCLKOUT
K3 LRCLK/DSD2B
L3 I2S3/DSD2A/HBR3
M3 DGND
N3 DVDDIO
P3 I2S0/DSD0B/HBR0
R3 DGND
T3 DGND
U3 P19
V3 P20
A4 RXD_0-
B4 RXD_0+
C4 CVDD
D4 DDCD_SDA
F4 EP_MOSI
G4 EP_SCK
H4 RAW_SYNC
J4 SPDIF/DSD0A
K4 SCLK
L4 I2S2/DSD1B/HBR2
M4 DGND
N4 DVDDIO
P4 I2S1/DSD1A/HBR1
R4 DGND
T4 DGND
Rev. F August 2010
Function
Connect this pin to ground
This pin is always connected to the Digital I/O
supply voltage (3.3 V).
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
This pin is always connected to the Terminator
supply voltage (3.3 V).
If RXA_5V, RXB_5V, RXC_5V and RXD_5V
are not used, float RXA_5V and set
DIS_CABLE_DET_RST to 0. if RX_A_5V is not
used but RXB_5V, RXC_5V or RXD_5V are
used, float RXA_5V.
Connect this pin to ground
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Connect this pin to ground
This pin is always connected to the Digital I/O
supply voltage (3.3 V).
Float this pin.
Connect this pin to ground
Connect this pin to ground
Float this pin.
Float this pin.
Float this pin.
Float this pin.
This pin is always connected to the Comparator
supply voltage (1.8 V).
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Connect this pin to ground
This pin is always connected to the Digital I/O
supply voltage (3.3 V).
Float this pin.
Connect this pin to ground
Connect this pin to ground
394
ADV7604
