Pin Mnemonic
V15 AIN1
A16 TVDD
B16 TVDD
C16 DGND
D16 TVDD
E16 DGND
F16 CVDD
H16 AVDD
J16 AVDD
K16 AVDD
L16 TRI7/HS_IN2
M16 TRI6
N16 TRI4
P16 AVDD
R16 TRI2
T16 SYNC2
U16 AVDD
V16 AIN2
A17 TVDD
B17 RXA_2+
C17 RXA_1+
D17 RXA_0+
E17 RXA_C+
F17 TVDD
Rev. F August 2010
Type Function
synchronization mode. User configurable.
Analog Video Analog video input channel.
Input
Power Terminator supply voltage (3.3 V).
Power Terminator supply voltage (3.3 V).
Ground Ground.
Power Terminator supply voltage (3.3 V).
Ground Ground.
Power Comparator supply voltage (1.8 V).
Power Analog supply voltage (1.8 V).
Power Analog supply voltage (1.8 V).
Power Analog supply voltage (1.8 V).
Misc Analog Dual purpose pin. Trilevel/bilevel input on the
SCART or D-terminal connector. Result
available via I2C. This signal can be buffered
and output to the FBOUT pin. HS on graphics
port 2. The HS input signal is used in CP
mode for 5-wire timing mode. HS_IN2 is a
3.3 V input that is 5 V tolerant.
Misc Analog Trilevel/bilevel input on the SCART or D-
terminal connector. Result available via I2C.
This signal can be buffered and output to the
FBOUT pin.
Misc Analog Trilevel/bilevel input on the SCART or D-
terminal connector. Result available via I2C.
This signal can be buffered and output to the
FBOUT pin.
Power Analog supply voltage (1.8 V).
Misc Analog Trilevel/bilevel input on the SCART or D-
terminal connector. Result available via I2C.
This signal can be buffered and output to the
FBOUT pin.
Misc Analog This is a synchronization on green or luma
input (SOG/SOY) used in embedded
synchronization mode. User configurable.
Power Analog supply voltage (1.8 V).
Analog Video Analog video input channel.
Input
Power Terminator supply voltage (3.3 V).
HDMI Input Digital input channel 2 complement of port A
in the HDMI interface.
HDMI Input Digital input channel 1 complement of port A
in the HDMI interface.
HDMI Input Digital input channel 0 complement of port A
in the HDMI interface.
HDMI Input Digital input clock complement of port A in
the HDMI interface.
Power Terminator supply voltage (3.3 V).
