6.4.1 Automatic Synchronization Configuration

In addition to configuring the analog input muxes, AIN_SEL[2:0] automatically controls the
associated synchronization channel routing for signals with embedded synchronization, for
example, Sync on Green (SOG) or Sync On Y (SOY) type signals.
SOG is associated with RGB input video; SOY is associated with component YPrPb input video.
Table 8 shows the routing details when AIN_SEL[2:0] is programmed.

6.4.2 Manual Synchronization Configuration

Figure 12 shows the two input synchronization muxes, which can be controlled manually as well as
automatically. This section describes the control bits for manual operation.
EMB_SYNC_1_SEL_MAN[1:0], Manual Sync configuration of EMB_SYNC_SEL_1 Path,
AFE Map, Address 0x15, [7:6]
Function
EMB_SYNC_1_SEL_MA
N[1:0]
00
01
10
11
EMB_SYNC_2_SEL_MAN[1:0], Manual Sync configuration of EMB_SYNC_SEL_2 Path,
AFE Map, Address 0x15, [5:4]
Function
EMB_SYNC_2_SEL_MAN[
1:0]
00
01
10
11
EMB_SYNC_SEL_MAN_EN, Manual Sync Configuration Enable, AFE Map, Address 0x2, [6]
Function
EMB_SYNC_SEL_MAN_E
N
0
1
Rev. F August 2010
Description
SYNC 1 pin routed to EMB_SYNC_SEL_1 path
SYNC 2 pin routed to EMB_SYNC_SEL_1 path
SYNC 3 pin routed to EMB_SYNC_SEL_1 path
SYNC 4 pin routed to EMB_SYNC_SEL_1 path
Description
SYNC 1 pin routed to EMB_SYNC_SEL_2 path
SYNC 2 pin routed to EMB_SYNC_SEL_2 path
SYNC 3 pin routed to EMB_SYNC_SEL_2 path
SYNC 4 pin routed to EMB_SYNC_SEL_2 path
Description
Configures automatic configuration of synchronization
muxing as per AIN_SEL[2:0] in
Manually route EMB_SYNC_SEL_1[1:0] (refer to
EMB_SYNC_1_SEL_MAN[1:0]) and
EMB_SYNC_SEL_2[1:0] (refer to
EMB_SYNC_2_SEL_MAN[1:0])
