11.10.1 Interrupt Mask Register Details

CCAP_AVL_MB1 , IO Map, Address 0x54, [0]
Function
CCAP_AVL_MB1
0
1
CCAP_AVL_MB2 , IO Map, Address 0x53, [0]
Function
CCAP_AVL_MB2
0
1
CGMS_WSS_AVL_MB1 , IO Map, Address 0x54, [2]
Function
CGMS_WSS_AVL_MB1
0
1
CGMS_WSS_AVL_MB2 , IO Map, Address 0x53, [2]
Function
CGMS_WSS_AVL_MB2
0
1
GS_PDC_VPS_UTC_AVL_MB1 , IO Map, Address 0x54, [4]
Function
GS_PDC_VPS_UTC_AVL_
MB1
0
1
GS_PDC_VPS_UTC_AVL_MB2 , IO Map, Address 0x53, [4]
Function
GS_PDC_VPS_UTC_AVL_MB2
0
1
Rev. F August 2010
Description
Disables interrupt on INT1 pin for CCAP_AVL signal from VDP
Enables interrupt on INT1 pin for CCAP_AVL signal from VDP
Description
Disables interrupt on INT2 pin for CCAP_AVL signal from VDP
Enables interrupt on INT2 pin for CCAP_AVL signal from VDP
Description
Disables interrupt on INT1 pin for WSS_CGMS_AVL signal from
VDP
Enables interrupt on INT1 pin for WSS_CGMS_AVL signal from
VDP
Description
Disables interrupt on INT2 pin for WSS_CGMS_AVL signal
from VDP
Enables interrupt on INT2 pin for WSS_CGMS_AVL signal from
VDP
Description
Disables interrupt on INT1 pin for GS, VPS, PDC, UTC_AVL
signal from VDP
Enables interrupt on INT1 pin for GS, VPS, PDC, UTC_AVL
signal from VDP
Description
Disables interrupt on INT2 pin for GS, VPS, PDC,
UTC_AVL signal from VDP
Enables interrupt on INT2 pin for GS, VPS, PDC,
UTC_AVL signal from VDP
