TRI7_LOWER_SLICE_LEVEL[1:0], Sets the lower slice level for TRI7 in trilevel slice mode,

AFE Map, Address 0x23, [1:0]

TRI7_LOWER_SLIC

E_LEVEL[1:0]

TRI8_LOWER_SLICE_LEVEL[1:0], Sets the lower slice level for TRI8 in trilevel slice mode,

AFE Map, Address 0x24, [1:0]

TRI8_LOWER_SLIC

E_LEVEL[1:0]

6.6.10 Trilevel Interrupts

for details of trilevel interrupts.
