Table 30: Ksv List Registers Location - Analog Devices Advantiv ADV7604 Hardware Manual

KSV Register Name
Number
0 KSV0[39:0]
1 KSV1[39:0]
2 KSV2[39:0]
3 KSV3[39:0]
4 KSV4[39:0]
5 KSV5[39:0]
6 KSV6[39:0]
7 KSV7[39:0]
8 KSV8[39:0]
9 KSV9[39:0]
Rev. F August 2010

Table 30: KSV List Registers Location

Register Addresses
0x80[7:0]: KSV0[7:0]
0x81[7:0]: KSV0[15:8]
0x82[7:0]: KSV0[23:16]
0x83[7:0]: KSV0[31:24]
0x84[7:0]: KSV0[39:32]
0x85[7:0]: KSV1[7:0]
0x86[7:0]: KSV1[15:8]
0x87[7:0]: KSV1[23:16]
0x88[7:0]: KSV1[31:24]
0x89[7:0]: KSV1[39:32]
0x8A[7:0]: KSV2[7:0]
0x8B[7:0]: KSV2[15:8]
0x8C[7:0]: KSV2[23:16]
0x8D[7:0]: KSV2[31:24]
8x8E[7:0]: KSV2[39:32]
0x8F[7:0]: KSV3[7:0]
0x90[7:0]: KSV3[15:8]
0x91[7:0]: KSV3[23:16]
0x92[7:0]: KSV3[31:24]
0x93[7:0]: KSV3[39:32]
0x94[7:0]: KSV4[7:0]
0x95[7:0]: KSV4[15:8]
0x96[7:0]: KSV4[23:16]
0x97[7:0]: KSV4[31:24]
0x98[7:0]: KSV4[39:32]
0x99[7:0]: KSV5[7:0]
0x9A[7:0]: KSV5[15:8]
0x9B[7:0]: KSV5[23:16]
0x9C[7:0]: KSV5[31:24]
0x9D[7:0]: KSV5[39:32]
0x9E[7:0]: KSV6[7:0]
0x9F[7:0]: KSV6[15:8]
0xA0[7:0]: KSV6[23:16]
0xA1[7:0]: KSV6[31:24]
0xA2[7:0]: KSV6[39:32]
0xA3[7:0]: KSV7[7:0]
0xA4[7:0]: KSV7[15:8]
0xA5[7:0]: KSV7[23:16]
0xA6[7:0]: KSV7[31:24]
0xA7[7:0]: KSV7[39:32]
0xA8[7:0]: KSV8[7:0]
0xA9[7:0]: KSV8[15:8]
0xAA[7:0]: KSV8[23:16]
0xAB[7:0]: KSV8[31:24]
0xAC[7:0]: KSV8[39:32]
0xAD[7:0]: KSV9[7:0]
0xAE[7:0]: KSV9[15:8]
0xAF[7:0]: KSV9[23:16]
