Bilevel/Trilevel Selection - Analog Devices Advantiv ADV7604 Hardware Manual

TRI4_SLICER_PWRD, AFE Map, Address 0x20, [6]
Function
TRI4_SLICER_PWRDN
0
1
TRI5_SLICER_PWRDN, AFE Map, Address 0x21, [6]
Function
TRI5_SLICER_PWRDN
0
1
TRI6_SLICER_PWRDN AFE Map, Address 0x22, [6]
Function
TRI6_SLICER_PWRDN
0
1
TRI7_SLICER_PWRDN, AFE Map, Address 0x23, [6]
Function
TRI7_SLICER_PWRDN
0
1
TRI8_SLICER_PWRDN, AFE Map, Address 0x24, [6]
Function
TRI8_SLICER_PWRDN
0
1

6.6.7 Bilevel/Trilevel Selection

Each slicer operates in bilevel slice mode by default. To switch between bilevel mode and trilevel
mode, use the following controls.
TRI1_BILEVEL_SLICE_EN, AFE Map, Address 0x1D, [5]
Function
TRI1_BILEVEL_SLI
CE_EN
0
1
Rev. F August 2010
Description
Powers up the TRI4 slicer
Powers down the TRI4 slicer
Description
Powers up the TRI5 slicer
Powers down the TRI5 slicer
Description
Powers up the TRI6 slicer
Powers down the TRI6 slicer
Description
Powers up the TRI7 slicer
Powers down the TRI7 slicer
Description
Powers up the TRI8 slicer
Powers down the TRI8 slicer
Description
Bilevel slicing mode
Trilevel slicing mode
79
ADV7604
