TRI5_READBACK[1:0], Readback for comparator results on TRI 5, AFE Map, Address 0x28,
[7:6]
Function
TRI5_READBACK[1:
0]
00
01
10
11
TRI6_READBACK[1:0], Readback for comparator results on TRI 6, AFE Map, Address 0x28,
[5:4]
Function
TRI6_READBACK[1:
0]
00
01
10
11
TRI7_READBACK[1:0], Readback for comparator results on TRI 7, AFE Map, Address 0x28,
[3:2]
Function
TRI6_READBACK[1:
0]
00
01
10
11
TRI8_READBACK[1:0], Readback for comparator results on TRI 8, AFE Map, Address 0x28,
[1:0]
Function
TRI8_READBACK[1:
0]
00
01
10
11
Rev. F August 2010
Description
Signal on TRI 5 is below lower slice level
Signal on TRI 5 has crossed lower slice level
Signal on TRI 5 has crossed upper slice level
Signal on TRI 5 has crossed upper slice level
Description
Signal on TRI 6 is below lower slice level
Signal on TRI 6 has crossed lower slice level
Signal on TRI 6 has crossed upper slice level
Signal on TRI 6 has crossed upper slice level
Description
Signal on TRI 7 is below lower slice level
Signal on TRI 7 has crossed lower slice level
Signal on TRI 7 has crossed upper slice level
Signal on TRI 7 has crossed upper slice level
Description
Signal on TRI 8 is below lower slice level
Signal on TRI 8 has crossed lower slice level
Signal on TRI 8 has crossed upper slice level
Signal on TRI 8 has crossed upper slice level
82
