Interrupt Status Register Details - Analog Devices Advantiv ADV7604 Hardware Manual

VITC_AVL_MB1 , IO Map, Address 0x54, [6]
Function
VITC_AVL_MB1
0
1
VITC_AVL_MB2 , IO Map Address 0x53, [6]
Function
VITC_AVL_MB2
0
1

11.10.2 Interrupt Status Register Details

CCAP_AVL_ST , IO Map, Address 0x52, [0], Read only
Function
CCAP_AVL_ST
0
1
CGMS_WSS_AVL_ST , IO Map, Address 0x52, [2], Read only
Function
CGMS_WSS_AVL_ST
0
1
GS_PDC_VPS_UTC_AVL_ST , IO Map, Address 0x52, [4], Read only
Function
GS_
PDC_VPS_UTC_AVL_
ST
0
1
VITC_AVL_ST , IO Map, Address 0x52, [6], Read only
Function
VITC_AVL_ST
0
1
Rev. F August 2010
Description
Disables interrupt on INT1 pin for VITC_AVL signal from VDP
Enables interrupt on INT1 pin for VITC_AVL signal from VDP
Description
Disables interrupt on INT2 pin for VITC_AVL signal from VDP
Enables interrupt on INT2 pin for VITC_AVL signal from VDP
Description
No detection of CCAP data by VDP module since this status bit last cleared
or unmasked
CCAP data detected by the VDP module since this status bit last cleared or
unmasked
Description
No detection of CGMS/WSS data by VDP module since this status
bit last cleared or unmasked
CGMS/WSS data detected by the VDP module or detected and
changed since this status bit last cleared or unmasked
Description
No detection of GemStar, PDC, UTC, or VC data by VDP module
since this status bit last cleared or unmasked
GemStar, PDC, UTC, or VC data detected by the VDP module or
GemStar, PDC, UTC, or VC data detected and changed since this
status bit last cleared or unmasked
Description
No detection of VITC data by VDP module since this status bit last cleared
or unmasked
VITC data detected by the VDP module since this status bit last cleared or
unmasked
342
ADV7604
