Analog Devices Advantiv ADV7604 Hardware Manual page 23

Pin Mnemonic
C9 DGND
D9 DGND
G9 DGND
H9 DGND
J9 DGND
K9 DGND
L9 DGND
M9 DGND
R9 DVDDIO
T9 DVDDIO
U9 P28
V9 P29
A10 RXC_C-
B10 RXC_C+
C10 DGND
D10 RTERM
G10 DGND
H10 DGND
J10 DGND
K10 DGND
L10 DGND
M10 DGND
R10 DGND
T10 DGND
U10 DGND
V10 DGND
A11 TVDD
B11 TVDD
C11 TVDD
D11 CVDD
G11 PVDD
H11 AGND
J11 AGND
K11 AGND
L11 AGND
M11 AGND
R11 FB_OUT
T11 RESETB
U11 P31
Rev. F August 2010
Type Function
HDMI interface.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Power Digital I/O supply voltage (3.3 V)
Power Digital I/O supply voltage (3.3 V)
Digital Video Video pixel output port
Output
Digital Video Video pixel output port
Output
HDMI Input Digital input clock complement of port C in
the HDMI interface.
HDMI Input Digital input clock true of port C in the HDMI
interface.
Ground Ground.
Misc Analog Sets internal termination resistance. A 500 Ω
resistor between this pin and GND should be
used.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Power Terminator supply voltage (3.3 V).
Power Terminator supply voltage (3.3 V).
Power Terminator supply voltage (3.3 V).
Power Comparator supply voltage (1.8 V).
Power PLL supply voltage (1.8 V).
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
Misc Digital FB output; this is the muxed fast blank output
from TRI1 to TRI8 (programmable).
Misc Digital Chip reset. Active low. Minimum low time for
a reset to take place is 5 ms.
Digital Video Video pixel output port.
23
ADV7604
