Table 9: Manual Input Muxing - Analog Devices Advantiv ADV7604 Hardware Manual

ADC_SWITCH_MAN, Manual input muxing enable, AFE Map, Address 0x02, [7]
Function
ADC_SWITCH_MAN
0
1
Once ADC_SW_MAN is set to 1, the following controls take effect.
ADC0_SW_MAN[3:0], ADC0 mux configuration, AFE Map, Address 0x03, [7:4]
Function
ADC0_SW_MAN[3:0]
0000
ADC1_SW_MAN[3:0], ADC1 mux configuration, AFE Map, Address 0x03, [3:0]
Function
ADC1_SW_MAN [3:0]
0000
ADC2_SW_MAN[3:0], ADC2 mux configuration, AFE Map, Address 0x04, [7:4]
Function
ADC2_SW_MAN [3:0]
0000
ADC0_SW_MAN[3:0],
ADC1_SW_MAN[3:0],
ADC2_SW_MAN[3:0]
Rev. F August 2010
Description
Automatic muxing
Manual muxing
Description
Configures muxing for ADC0 according to
Description
Configures muxing for ADC1 according to
Description
Configures muxing for ADC2 according to

Table 9: Manual Input Muxing

ADC0
Connected to
0000 No connection
0001 AIN1
0010 No connection
0011 No connection
0100 AIN4
0101 No connection
0110 No connection
0111 AIN7
1000 No connection
1001 AIN9
1010 AIN10
1011 No connection
1100 No connection
1101 No connection
1110 No connection
1111 No connection
ADC1
Connected to
No connection
No connection
AIN2
No connection
AIN4
AIN5
No connection
No connection
AIN8
No connection
No connection
AIN11
No connection
No connection
No connection
No connection
69
ADV7604
Table 9
Table 9
Table 9
ADC2
Connected to
No connection
No connection
No connection
AIN3
AIN4
AIN5
AIN6
No connection
No connection
AIN9
No connection
No connection
AIN12
No connection
No connection
No connection
