Pin Mnemonic
R14 AGND
T14 AGND
U14 AGND
V14 AGND
A15 RXB_C-
B15 RXB_C+
C15 DGND
D15 DDCA_SDA
E15 DGND
F15 DGND
H15 XTALP
J15 XTALN
K15 AVDD
L15 VS_IN2
M15 TRI5
N15 TRI3
P15 AVDD
R15 Y_MUX_OUT
T15 TRI1
U15 SYNC1
Rev. F August 2010
Type Function
is a 3.3 V input that is 5 V tolerant.
Ground Ground.
Ground Ground.
Ground Ground.
Ground Ground.
HDMI Input Digital input clock complement of port B in
the HDMI interface.
HDMI Input Digital input clock true of port B in the HDMI
interface.
Ground Ground.
HDMI Input HDCP slave serial clock port A. DDCA_SDA
is a 3.3 V input that is 5 V tolerant.
Ground Ground.
Ground Ground.
Misc Analog Input pin for 28.63636 MHz crystal or can be
overdriven by an external 1.8 V 28.63636
MHz clock oscillator source to clock the
ADV7604.
Misc Analog This pin should be connected to the 28.63636
MHz crystal or left as a no connect if an
external 1.8 V 28.63636 MHz clock oscillator
source is used to clock the ADV7604. In
crystal mode, the crystal must be a
fundamental crystal.
Power Analog supply voltage (1.8 V).
Misc Analog Dual purpose pin. Trilevel/bilevel input on the
SCART or D-terminal connector. Result
available via I2C. This signal can be buffered
and output to the FBOUT pin. VS on graphics
port 2. The VS input signal is used in CP
mode for 5-wire timing mode. VS_IN2 is a
3.3 V input that is 5 V tolerant.
Misc Analog Trilevel/bilevel input on the SCART or D-
terminal connector. Result available via I2C.
This signal can be buffered and output to the
FBOUT pin.
Misc Analog Trilevel/bilevel input on the SCART or D-
terminal connector. Result available via I2C.
This signal can be buffered and output to the
FBOUT pin.
Power Analog supply voltage (1.8 V).
Misc Analog Buffered output of the Y channel.
Misc Analog Trilevel/bilevel input on the SCART or D-
terminal connector. Result available via I2C.
This signal can be buffered and output to the
FBOUT pin.
Misc Analog This is a synchronization on green or luma
input (SOG/SOY) used in embedded
25
