DCM_FILT_SEL, DPP Map, Address 0x29, [1:0]
The DCM_FILT_SEL
filters. For the selection to be effective, manual control must be enabled by DCM_FILT_MAN_EN.
Function
DCM_FILT_SEL
00
01
10
11

Figure 52: Manual and Default DCM Filter Response Selection

Rev. F August 2010
bit controls the manual selection of the filter response for the decimation
Description
Bypass decimation filters
DCM filter response with Fc = 0.26 * Fs/2 (blue in
DCM filter response with Fc = 0.43 * Fs/2 (red in
DCM filter response with Fc = 0.66 * Fs/2 (green in
52)
192
ADV7604
Figure 52)
Figure 52)
Figure
