Register Access Conventions

Mode Description
R/W Memory location has read and write access.
Read only Memory location is read access only. A read
always returns 0 unless specified otherwise.
Write only Memory location is write access only.
1.6

Acronyms and Abbreviations

Acronym/Abbreviation
ACP
ADC
AFE
AGC
AVI
BGA
CP
CSC
CSync
DID
DCM
DDR
DDFS
DE
DLL
DPP
DSD
DST
DVI
DUT
EAV
ECT
ED
E-EDID
EMC
EOM
EQ
HD
HDCP
HDMI
HDTV
HSync
IC
ISRC
Rev. F August 2010
Description
Audio Content Protection
Analog to Digital Converter
Analog Front End
Automatic Gain Control
Auxiliary Video Information
Ball Grid Array
Component Processor
Color Space Converter/Conversion
Composite Synchronization
Data Identification Word
Decimation
Double Data Rate
Direct Digital Frequency Synthesizer
Data Enable
Delay Locked Loop
Data Preprocessor
Direct Stream Digital
Direct Stream Transport
Digital Visual Interface
Device Under Test (designate the ADV7604 unless stated
otherwise)
End of Active Video
Extended Command Table
Enhanced Definition
Enhanced-Extended Display Identification Data
Configuration
Electromagnetic Compatibility
End of Message
Equalizer
High Definition
High Bandwidth Digital Content Protection
High Bandwidth Multimedia Interface
High Definition Television
Horizontal Synchronization
Integrated Circuit
International Standard Recording Code
