TRI4_UPPER_SLICE_LEVEL[2:0], Sets the upper slice level for TRI4, AFE Map, Address
0x20, [4:2]
Function
TRI4_UPPER_SLICE
_LEVEL[2:0]
000
001
010
011
100
101
110
111
TRI5_UPPER_SLICE_LEVEL[2:0], Sets the upper slice level for TRI5, AFE Map, Address
0x21, [4:2]
Function
TRI5_UPPER_SLICE
_LEVEL[2:0]
000
001
010
011
100
101
110
111
TRI6_UPPER_SLICE_LEVEL[2:0], Sets the upper slice level for TRI6, AFE Map, Address
0x22, [4:2]
Function
TRI6_UPPER_SLICE
_LEVEL[2:0]
000
001
010
011
100
101
110
111
Rev. F August 2010
675 mV
825 mV
975 mV
1.125 V
Description
75 mV
225 mV
375 mV
525 mV
675 mV
825 mV
975 mV
1.125 V
Description
75 mV
225 mV
375 mV
525 mV
675 mV
825 mV
975 mV
1.125 V
Description
75 mV
225 mV
375 mV
525 mV
675 mV
825 mV
975 mV
1.125 V
