The host must set the destination logical address of the messages that the CEC receive module
processes and acknowledges via the following registers:
• CEC_LOGICAL_ADDRESS0[3:0] if CEC_LOGICAL_ADDRESS_MASK[0] is set to 1
• CEC_LOGICAL_ADDRESS1[3:0] if CEC_LOGICAL_ADDRESS_MASK[1] is set to 1
• CEC_LOGICAL_ADDRESS2[3:0] if CEC_LOGICAL_ADDRESS_MASK[2] is set to 1
CEC_LOGICAL_ADDRESS0[3:0], Logical Address 0 , CEC Map, Address 0x28, [3:0]
Function
CEC_LOGICAL_A
DDRESS0[3:0]
xxxx
1111
CEC_LOGICAL_ADDRESS1[3:0], Logical Address 1 , CEC Map, Address 0x28, [7:4]
Function
CEC_LOGICAL_A
DDRESS1[3:0]
xxxx
1111
CEC_LOGICAL_ADDRESS2[3:0], Logical Address 2 , CEC Map, Address 0x29, [3:0]
Function
CEC_LOGICAL_A
DDRESS2[3:0]
xxxx
1111
CEC_LOGICAL_ADDRESS_MASK[2:0], Logical Address Mask , CEC Map, Address 0x27,
[6:4]
Function
CEC_LOGICAL_A
DDRESS_MASK[2
:0]
xxx
001
Figure 116 shows the state machine implemented in the CEC block when it acts as a follower.
Rev. F August 2010
Description
Logical address used by CEC receive section if
CEC_LOGICAL_ADDRESS_MASK[0] set to 1
Default value
Description
Logical address used by CEC receive section if
CEC_LOGICAL_ADDRESS_MASK[1] set to 1
Default value
Description
Logical address used by CEC receive section if
CEC_LOGICAL_ADDRESS_MASK[2] set to 1
Default value
Description
Logical address mask for the CEC receive module
Default value
