RGB_OUT, IO Map, Address 0x02, [1]
RGB_OUT is used in conjunction with the INP_COLOR_SPACE[3:0] and
select the applied CSC (refer to Table 45). It sets up the output color space and the correct digital
blank level and offsets on the RGB or YPrPb outputs.
Function
RGB_OUT
0
1
ALT_GAMMA , IO Map, Address 0x02, [3]
ALT_GAMMA is used in conjunction with the INP_COLOR_SPACE[3:0] and
select the applied CSC (refer to
formats, irrespective of the input formats. If this bit is set, it gives an output that is in a different
format from the input.
Function
ALT_GAMMA
0
1
INP_COLOR_SPACE[3:
0]
(Input Color Space)
00
RGB
01
(YCrCb/YUV 601)
10
(YCrCb/YUV 709)
Rev. F August 2010
Description
Output color space is YUV
Output color space is RGB
Table 45). The output YUV can be in the YUV601 or YUV709
Description
YUV601 input, RGB_OUT = 0 – YUV601 output
YUV709 input, RGB_OUT = 0 – YUV709 output
YUV601 input, RGB_OUT = 0 – YUV709 output
YUV709 input, RGB_OUT = 0 – YUV601 output

Table 45: Automatic CSC Selection

RGB_OUT
ALT_GAMMA = 0
0
1
0
1
0
1
CSC Mode Used
(Output)
YCrCb 601
RGB
YCrCb 601
RGB
YCrCb 709
RGB
206
ALT_GAMMA
RGB_OUT
ALT_GAMMA = 1
YCrCb 709
RGB
YCrCb 709
RGB
YCrCb 601
RGB
ADV7604
bits to
bits to
