Equation 3: TMDS Frequency in MHz (Measured Before TMDS PLL)
TMDSFREQ_RAW[7:0], HDMI Map, Address 0x52, [7:0]
Function
TMDSFREQ_RA
W[7:0]
xxxxxxxx

7.11 Deep Color Mode Support

The ADV7604 supports HDMI streams with deep color modes of 24, 30, or 36 bits per sample. The
addition of a video FIFO (refer to Section 7.12) allows for the robust support of these modes.
The deep color mode information that the ADV7604 extracts from the general control packets can be
read back from DEEP_COLOR_MODE. It is possible to override the deep color mode that the
ADV7604 uses to unpack the video data encapsulated in the processed HDMI stream by configuring
the OVERRIDE_DEEP_COLOR_MODE
DEEP_COLOR_MODE, HDMI Map, Address 0x0B, [6:5]
Function
DEEP_COLOR_MODE
00
01
10
11
OVERRIDE_DEEP_COLOR_MODE, Deep Color Mode Override, HDMI Map, Address 0x40,
[6]
Function
DEEP_COLOR_MODE
0
1
Rev. F August 2010
=
F TMDSFREQ
TMDS
Description
Outputs 8-bit TMDS frequency measurement
and DEEP_COLOR_MODE_USER[1:0] controls.
Description
Color depth is 24 bits per pixel
Color depth is 30 bits per pixel
Color depth is 36 bits per pixel
Color depth is 48 bits per pixel (not supported)
Description
Normal operation. HDMI section unpacks video data according to
deep color information extracted from general control packets.
Overrides deep color mode extracted from general control packets.
HDMI section unpacks video data according to deep color mode
set in DEEP_COLOR_MODE_USER[1:0].
_
RAW
