Table 37: Hdmi Flags In Io Map Register 0X79 - Analog Devices Advantiv ADV7604 Hardware Manual

Bit Name
NEW_AVI_INFO_RAW
NEW_AUDIO_INFO_RAW
NEW_SPD_INFO_RAW
NEW_MS_INFO_RAW
NEW_VS_INFO_RAW
NEW_ACP_PCKT_RAW
NEW_ISRC1_PCKT_RAW
NEW_ISRC2_PCKT_RAW
Bit Name
NEW_GAMUT_MDATA_RAW
AUDIO_PCKT_ERR_RAW
PACKET_ERROR_RAW
Rev. F August 2010
Bit Position
0 (LSB)
1
2
3
4
5
6
7

Table 37: HDMI Flags in IO Map Register 0x79

Bit Position
0 (LSB)
1
2
186
Description
Returns 1 if an AVI InfoFrame with new
content has been received. Reset to 0 by
setting NEW_AVI_INFO_CLR (IO
Map, Address 0x76[0]) to 0.
Returns 1 if an Audio InfoFrame with
new content has been received. Reset to
0 by setting NEW_AUDIO_INFO_CLR
(IO Map, Address 0x76[1]) to 0.
Returns 1 if an SPD InfoFrame with
new content has been received. Reset to
0 by setting NEW_SPD_INFO_CLR
(IO Map, Address 0x76[2]) to 0.
Returns 1 if a MPEG InfoFrame with
new content has been received. Reset to
0 by setting NEW_MS_INFO_CLR (IO
Map, Address 0x76[3]) to 0.
Returns 1 if a Vendor Specific
InfoFrame with new content has been
received. Reset to 0 by setting
NEW_VS_INFO_CLR (IO Map,
Address 0x76[4]) to 0.
Returns 1 if an ACP packet with new
content has been received. Reset to 0 by
setting NEW_ACP_PCKT _CLR (IO
Map, Address 0x76[5]) to 0.
Returns 1 if an ISRC1 packet with new
content has been received. Reset to 0 by
setting NEW_ISRC1_PCKT _CLR (IO
Map, Address 0x76[7]) to 0.
Returns 1 if an ISRC2 packet with new
content has been received. Reset to 0 by
setting NEW_ISRC2_PCKT _CLR (IO
Map, Address 0x76[7]) to 0.
Description
Returns 1 if a Gamut Metadata
packet with new content has been
received. Reset to 0 by setting
NEW_GAMUT_MDATA _CLR (IO
Map, Address 0x7B[0]) to 0.
Returns 1 if an uncorrectable ECC
error was detected in the body of an
audio Packet. Also returns 1 if an
audio packet error is observed in a
HBR or DSD stream. Reset to 0 by
setting AUDIO_PCKT_ERR_ST (IO
Map, Address 0x7B[1])
Returns 1 if an uncorrectable ECC
error has been detected in the header
or the body of a packet. Reset to 0 by
setting PACKET_ERROR _ST (IO
ADV7604
