Pin Mnemonic
A7 RXC_2-
B7 RXC_2+
C7 TVDD
D7 DDCC_SCL
G7 DGND
H7 DGND
J7 DVDD
K7 DVDD
L7 DVDD
M7 DVDD
R7 INT1
T7 SDA
U7 P26
V7 P27
A8 RXC_1-
B8 RXC_1+
C8 DGND
D8 CVDD
G8 DGND
H8 DGND
J8 DGND
K8 DVDD
L8 DVDD
M8 DVDD
R8 CLAMPIN
T8 SYNC_OUT/INT2
U8 DCLKIN
V8 LLC
A9 RXC_0-
B9 RXC_0+
Rev. F August 2010
Type Function
HDMI Input Digital input channel 2 complement of port C
in the HDMI interface.
HDMI Input Digital input channel 2 true of port C in the
HDMI interface.
Power Terminator supply voltage (3.3 V).
HDMI Input HDCP slave serial clock port C. DDCC_SCL
is a 3.3 V input that is 5 V tolerant.
Ground Ground.
Ground Ground.
Power Digital supply voltage (1.8 V).
Power Digital supply voltage (1.8 V).
Power Digital supply voltage (1.8 V).
Power Digital supply voltage (1.8 V).
Misc Digital Interrupt pin 1, can be active low or active
high. When status bits change, this pin is
triggered. The events that trigger an interrupt
are under user control.
Misc Digital I2C port serial data input/output pin. SDA is
the data line for the control port.
Digital Video Video pixel output port.
Output
Digital Video Video pixel output port.
Output
HDMI Input Digital input channel 1 complement of port C
in the HDMI interface.
HDMI Input Digital input channel 1 true of port C in the
HDMI interface.
Ground Ground.
Power Comparator supply voltage (1.8 V).
Ground Ground.
Ground Ground.
Ground Ground.
Power Digital supply voltage (1.8 V).
Power Digital supply voltage (1.8 V).
Power Digital supply voltage (1.8 V).
External External clamp signal. This is an optional
Clamp mode of operation for the ADV7604.
Misc Digital Interrupt pin 2, can be active low or active
high. When status bits change, this pin is
triggered. The events that trigger an interrupt
are under user control.
External Clock External clock for ADC sampling. This is an
and Clamp optional mode of operation for the ADV7604.
Digital Video Line locked output clock for the pixel data
Output (range is 13.5 MHz to 170 MHz).
HDMI Input Digital input channel 0 complement of port C
in the HDMI interface.
HDMI Input Digital input channel 0 true of port C in the
