CP_END_VBI_EVEN[11:0], CP Map, Address 0xA9 [3:0] and 0xAA, [7:0]
CP_END_VBI_EVEN[11:0] specifies the line number where the VBI region ends. This is used for
even fields when the decoder is processing an interlaced input and not used when the decoder is
processing a progressive input.
Function
CP_END_VBI_EVEN
[11:0]
0x0
xxxxxxxxxxxx
It is also possible to adjust the position of the HSync and VSync signals. The following controls to
adjust these are signed numbers to allow adjustment in either direction from the current position:
•
START_HS[9:0],
•
END_HS[9:0],
•
START_VS[3:0],
•
END_VS[3:0],

10.15.3 Auxiliary Auto Graphics Controls

This section describes the auxiliary control available for auto graphic controls. It is recommended to
leave this control to default.
IGNR_CLMP_VS_MAR_START[4:0], CP Map, Address 0x8A, [0], Address 0x8B, [7:4]
Function
IGNR_CLMP_VS_M
AR_START [4:0]
0x4
xxxxx
IGNR_CLMP_VS_MAR_END[4:0], CP Map, Address 0x8A, [7:3]
Function
IGNR_CLMP_VS_M
AR_END [4:0]
0x04
xxxxx
Rev. F August 2010
Description
Default value. Total number of line at start of an even field of interlaced
is set to IGNR_CLMP_VS_MAR_END [4:0].
standard
Sets the total number of line at start of an even field of interlaced
standard
CP Map, Address 0x7C, [3:2] and 0x7E, [7:0]
CP Map, Address 0x7C, [1:0] and 0x7D, [7:0]
CP Map, Address 0x7F, [7:4]
CP Map, Address 0x7F, [3:0]
Description
Default value.
Sets start of window during which the clamp is ignored. This register
stores unsigned number of pixel clocks between start position of the
window relative to leading edge of the VSync. This control should
only be used when VID_STD[5:0] is set for auto graphics mode.
Description
Default value.
Sets end of window during which the clamp is ignored. This register
stores unsigned number of pixel clocks between end position of
window relative to leading edge of the VSync. This control should
only be used when VID_STD[5:0] is set for auto graphics mode.
