Interrupts
AKSV_UPDATE_ST
Note: The TMDS activity on the selected HDMI port is indicated as follows:
•
TMDS_CLK_A_RAW
port
•
TMDS_CLK_B_RAW
port
•
TMDS_CLK_C_RAW
port
•
TMDS_CLK_D_RAW
port
14.1.5.3 Group 3 HDMI Interrupts
The interrupts listed in
• The ADV7604 is configured in HMDI mode
• There is a TMDS activity on the selected HDMI port (refer to Section 14.1.5.2)
•
VIDEO_PLL_LOCKED_RAW
Interrupts
ISRC2_PCKT_ST
ISRC1_PCKT_ST
ACP_PCKT_ST
VS_INFO_ST
MS_INFO_ST
SPD_INFO_ST
AUDIO_INFO_ST
AVI_INFO_ST
CS_DATA_VALID_ST
AV_MUTE_ST
AUDIO_CH_MD_ST
AUDIO_MODE_CHANGE_ST 0x66[3]
GEN_CTL_PCKT_ST
AUDIO_C_PCKT_ST
GAMUT_MDATA_ST
HDMI_MODE_ST
HDMI_ENCRPT_ST
NEW_ISRC2_PCKT_ST
NEW_ISRC1_PCKT_ST
NEW_ACP_PCKT_ST
NEW_VS_INFO_ST
Rev. F August 2010
is set to 1 (IO Map, Address 0x6A[4]) if port A is the active HDMI
is set to 1 (IO Map, Address 0x6A[3]) if port B is the active HDMI
is set to 1 (IO Map, Address 0x6A[2]) if port C is the active HDMI
is set to 1 (IO Map, Address 0x6A[1]) if port D is the active HDMI
Table 92 are valid under the following conditions:
is set to 1 (IO Map, Address 0x6A[6])

Table 92: HDMI Interrupts Group 3

IO Map Location
0x79[5]
IO Map Location
0x61[7]
0x61[6]
0x61[5]
0x61[4]
0x61[3]
0x61[2]
0x61[1]
0x61[0]
0x66[7]
0x66[5]
0x66[4]
0x66[2]
0x66[1]
0x66[0]
0x6B[0]
0x70[0]
0x75[7]
0x75[6]
0x75[5]
0x75[4]
378
ADV7604
