To disable the DLL on the LLC: first, bypass the DLL by setting
disable the DLL by setting
LLC_DLL_EN, DLL Enable, AFE Map , Address 0x13, [7]
Function
LLC_DLL_EN
0
1
LLC_DLL_MUX, IO Map, Address 0x33, [6]
Function
LLC_DLL_MUX
0
1
LLC_DLL_PHASE[4:0], DLL Phase Selection, AFE Map, Address 0x13, [4:0]
Function
LLC_DLL_PHASE[4
:0]
0000
xxxx
3.8

CP and HDMI Simultaneous Mode

The ADV7604 can be configured to be in either simultaneous mode or non simultaneous mode, as
follows:
• Non simultaneous mode
In this mode, the ADV7604 will process either analog or HDMI/DVI inputs. The HDMI
section is disabled when the ADV7604 is configured to process analog inputs. The ADCs are
powered down when the part is configured to process HDMI/DVI inputs in HDMI mode.
• Simultaneous mode
In this mode, specific subsections of the HDMI block remain enabled when the ADV7604 is
programmed to process analog inputs through the CP core. Simultaneous mode keeps the
HDCP engine and the EDID/Repeater controller active, allowing an upstream transmitter to
authenticate the ADV7604 even when the latter is in analog mode. Keeping the HDCP engine
active allows for fast switching from analog mode to HDMI mode, as the transmitter will
have already authenticated the ADV7604 when the latter is switched into HDMI mode.
Notes:
• Simultaneous mode only affects the ADV7604 when the latter is programmed to process
analog inputs through the CP core.
• Simultaneous mode has no effect when the part is programmed in HDMI mode as the full
HDMI section is enabled in this mode.
• The ADCs are powered down automatically in HDMI mode.
Rev. F August 2010
LLC_DLL_EN to 0.
Description
Powers down the DLL on LLC
Powers up the DLL on LLC
Description
Bypasses the DLL
Muxes the DLL output on the LLC output pin
Description
Default
Sets one of the 32 phases of the DLL to vary LLC CLK
LLC_DLL_MUX
46
ADV7604
to 0. Then,
