Analog Devices Advantiv ADV7604 Hardware Manual page 407

Revision Date
Rev B 11/2008
Rev. C 12/2008
Rev. F August 2010
Changes
Section 7.16.2
Corrected the location of the FIFO status registers
Section 7.18.7
Corrected the name of CS_COPYRIGHT_FORCE register to
CS_COPYRIGHT_MANUAL.
Section 7.19.1.2
The description of the registers listed in this section has been
revised.
Section 7.20.1.2
Corrected 'BCAPS[0] to 'BCAPS[5]'.
Section 12
This section has been revised
Section 13
This section has been revised
Section 5.2
Updated Figure 7
Appendix B
Updated Table 92
Section 3.1
This section has been updated
Section 1
Section 1.7 reviewed. Now Section 1.8
Section 1.7 added
Section 2
Updated Table 1. Format for pin allocation changed to alpha-
numeric
Section 4 reviewed
Section 5 reviewed
Section 6.4.1 reviewed
Section 6.6.3 reviewed
Section 7 reviewed
Section 8.3 updated
Sections 8.4.1, 8.4.3, and 8.4.5 updated
Section 8.4.6 added
Section 10.7 added
Section 10.7 updated. Now Section 10.8
Section 10.8 updated. Now Section 10.9
Section 10.10 now Section 10.11
Section 10.11 now Section 10.12
Section 10.12 now Section 10.13
Section 10.14 updated. Now Section 10.15
Section 12.6.3 - Updated Figure 118
Appendix B - Updated Table 94. Format for pin allocation
changed to alpha-numeric
