Text Packets
(X/01 to X/25)
8/30 (Format 1)
Packet
Desig Code = 0000 or
0001
UTC
8/30 (Format 2)
Packet
Desig Code = 0010 or
0011
PDC
X/26 , X/27, X/28,
X/29, X/30, X/31
(X/26, X/28 and M/29
further decoding
needs 24x18 hamming
decoding. Not
supported at present.)
SOFT_ERROR_CORRECTION_EN , VDP Map, Address 0x60, [4]
Function
SOFT_ERROR_CORRECTION_E
N
0
1
SOFT_ERROR_CORRECTION_MODE , VDP Map, Address 0x60, [6:5]
Function
SOFT_ERROR_CORRECTION_M
ODE
00
01
10
11
Rev. F August 2010
Bytes 11 to 42
Byte 1
Byte 2
Bytes 3 to 42
Byte 1
Byte 2
Byte 3
Bytes 4 to 10
Bytes 11 to 23
Bytes 24 to 42
Byte 1
Byte 2
Byte 3
Bytes 4 to 10
Byte 11 to 23
Byte 24 to 42
Byte 1
Byte 2
Byte 3
Byte 4 to 42
Description
Disables error correction of decoded data.
Enables error correction of decoded data. Significant only
if hamming code operation is disabled (0x60[7]).
Description
Majority voting logic (MVL) based error correction.
Sigma deviation based error correction.
Corrects weak bit identified by both modes. If no common
bit is identified, bit identified by Sigma deviation methods
is corrected.
Corrects weak bit identified by both modes. If no common
bit is identified, bit identified by MVL method is
corrected.
329
Raw data bytes
Mag No. – dehammed byte 4
Row No. – dehammed byte 5
Raw data bytes
Mag No. – dehammed byte 4
Row No. – dehammed byte 5
Desig Code. – dehammed byte 6
Dehammed Initial Teletext page bytes 7 to
12
UTC bytes – dehammed bytes 13 to 25
Raw Status bytes
Mag No. – dehammed byte 4
Row No. – dehammed byte 5
Desig Code. – dehammed byte 6
Dehammed Initial Teletext Page byte 7 to
12
PDC bytes – dehammed bytes 13 to 25
Raw Status bytes
Mag No. – dehammed byte 4
Row No. – dehammed byte 5
Desig Code. – dehammed byte 6
Raw Data bytes
