CH2_TRIG_SSPD Trigger Synchronization Source and Polarity Detector for channel 2 , CP
Map, Address 0x41, [2]
Function
CH2_TRIG_SSPD
0
CH1_SYNC_SRC[1:0] SSPD Synchronization Source Selection for channel 1 , CP Map,
Address 0x85, [4:3]
Function
CH1_SYNC_SRC[1:0]
00
01
10
11
CH2_SYNC_SRC[1:0] SSPD Synchronization Source Selection for channel 2 , CP Map,
Address 0x41, [4:3]
Function
CH2_SYNC_SRC[1:0]
00
01
10
11
CH1_POL_MAN_EN Manual Overwrite for Polarity Detection SSPD in channel 1 , CP Map,
Address 0x85, [7]
Function
CH1_POL_MAN_
EN
0
1
CH2_POL_MAN_EN Manual Overwrite for Polarity Detection SSPD in channel 2 , CP Map,
Address 0x41, [7]
Function
CH2_POL_MAN_
EN
0
1
Rev. F August 2010
Description
0 to 1 transition on CH2_TRIG_SSPD causes channel 2 SSPD block to
examine currently presented synchronization signals. CH2_TRIG_SSPD
bit is not self clearing – must be reset by user to prepare for next trigger.
Description
Auto detect mode for synchronization source – uses results of auto
detection for synchronization signal routing.
Result can be read back via
Manual setting: separate HSync and VSync to channel 1 SSPD
Manual setting: CSync on HSync input to channel 1
Manual setting: embedded synchronization signal input to channel 1
Description
Auto detect mode for synchronization source – uses results of auto
detection for synchronization signal routing.
Result can be read back via
Manual setting: separate HSync and VSync to channel 2 SSPD
Manual setting: CSync on HSync input to channel 2
Manual setting: embedded synchronization signal input to channel 2
Description
Uses result from channel 1 SSPD polarity auto detection
Manual overwrite: uses CH1_POL_VS and CH1_POL_HS
Description
Uses result from channel 2 SSPD polarity auto detection
Manual overwrite: uses CH2_POL_VS and CH2_POL_HS
CH1_CUR_SYNC[1:0]
CH2_CUR_SYNC[1:0]
261
ADV7604
bits.
bits.
