VDP_TTXT_TYPE[1:0] (VDP) , VDP Map, Address 0x60, [1:0]
VDP_TTXT_TYPE[1:0] specifies the Teletext type to be decoded. These bits are functional only if
VDP_TTXT_TYPE_MAN_EN is set to 1.
Function
VDP_TTXT_TYPE
[1:0]
00
01
10
11

11.4 VDP Configuration

The VDP configuration bits help in programming or selecting some aspects of VBI decoding.
NOISE_CLK_DISABLE (VDP) , VDP Map, Address 0x61, [5]
The noise clock counter is a feature that counts the duration of clock run in (CRI) bits for a particular
standard. Disabling this feature allows the detection of clock run in through the counting of edges
only.
Function
NOISE_CLK_DISABLE
0
1
SLICE_CORRECTOR_ENABLE , VDP Map, Address 0x9D, [1]
A slice corrector is required to allow the decoding of nonstandard data. This feature combines both
the delay based skipping of CRI and the functionality of skip CRI to jump to a suitable position from
which a framing code (FC) can be searched.
Function
SLICE_CORRECTOR_ENABLE
0
1
Rev. F August 2010
Description
625/50
Teletext-ITU-BT.653- 625/50-A
Teletext-ITU-BT.653- 625/50-B
(WST)
Teletext-ITU-BT.653- 625/50-C
Teletext-ITU-BT.653- 625/50-D
Description
Enables noise clock feature for clock run in detection
Disables noise clock feature for clock run in detection
Description
Disables slice corrector feature
Enables slice corrector feature. This helps in handling
nonstandard data.
327
525/60
Reserved
Teletext-ITU-BT.653-525/60-
B
Teletext-ITU-BT.653-525/60-
C or EIA516 (NABTS)
Teletext-ITU-BT.653-525/60-
D
ADV7604
